EcoSky Series Thermally Efficient Unit Skylights

Our Acrylite® Satin Sky® 2 glazing is an innovative acrylic sheet that is a powerful heat reflector which greatly reduces solar heat gain, making it ideal for both hot and cold climates. Satin Sky 2 is infrared blocking, light diffusing, and 100% haze white.

EcoSky3 units are available with Lumira® aerogel filled multiwall polycarbonate laylites for improved thermal performance and excellent light diffusion with SHGC of .31 and a high VLT for maximum usable LUX delivery. These models meet IECC 2018 requirements in all climate zones.



Download BIM Models for Revit®

Curb Mount:

Deck Mount:



  • Curb Mount
  • Deck Mount
  • Standard Sizes
  • Performance Values
  • Safety Considerations

EcoSky
CEC2 – Double Dome
CFC2 – Double Dome, Pyramid Outer
CEC3 – Triple Dome

EcoSky3
CLC2 – Single Dome with Aerogel Filled Laylite
CMC2 – Single Pyramid Dome with Aerogel Filled Laylite
CLC3 – Double Dome with Aerogel Filled Laylite
CMC3 – Double Dome with Aerogel Filled Laylite, Pyramid Outer

  • For use on 1½” thick site-built or prefabricated curbs
  • No exposed fasteners
  • Fully assembled with extruded aluminum retainer frame welded at corners and high performance weather seals
  • Heat welded one-piece curb frame construction: chambered extruded PVC curb frame with integral condensation gutter and counterflashing downward leg
  • Aluminum retainer frame finish:
    • Mill (Standard)
    • 2605 FEVE Powder Coat, 2605 PVDF, 2604 Powder Coat, and Anodized (more information)
  • Safety screens available

EcoSky
CED2 – Double Dome
CFD2 – Double Dome, Pyramid Outer
CED3 – Triple Dome

EcoSky3
CLD2 – Single Dome with Aerogel Filled Laylite
CMD2 – Single Pyramid Dome with Aerogel Filled Laylite
CLD3 – Double Dome with Aerogel Filled Laylite
CMD3 – Double Dome with Aerogel Filled Laylite, Pyramid Outer

  • Curb heights available in 12″ or 16″
  • Heat welded one-piece curb frame construction: sloped and chambered extruded PVC curb frame with integral condensation gutter and counterflashing downward leg
  • Aluminum curb with 1½” rigid insulation – mill finish outer, white inner, with HS adhesive clamping at corners
  • Fully assembled with corrosion proof screws and high performance weather seals
  • Aluminum retainer frame finish: Mill (standard), anodized, Kynar 500, baked enamel (more information)
  • Safety screens available
Size Curb Mount O.D. of Curb Deck Mount Rough Opening
2828 25 ¼” x 25 ¼” 22 ¼” x 22 ¼”
2852 25 ¼” x 49 ¼” 22 ¼” x 46 ¼”
3636 33 ¼” x 33 ¼” 30 ¼” x 30 ¼”
3652 33 ¼” x 49 ¼” 30 ¼” x 46 ¼”
4242 40″ x 40″ 37″ x 37″
4280 40″ x 78″ 37″ x 75″
5252 49 ¼” x 49 ¼” 46 ¼” x 46 ¼”
5276 49 ¼” x 72 ½” 46 ¼” x 69 ½”
5296 49 ¼” x 92 ½” 46 ¼” x 89 ½”
5555 51″ x 51″ 48″ x 48″
55102 51″ x 99″ 48″ x 96″
6060 58″ x 58″ 55″ x 55″
6476 60 ½” x 72 ½” 57 ½” x 69 ½”
6496 60 ½” x 92 ½” 57 ½” x 89 ½”

Custom Sizes Available



Curb Mount

Model U-Value SHGC VT
CEC2 .61 .45 60%
CLC3 .33 .31 40%

Deck Mount

Model U-Value SHGC VT
CED2 .66 .45 60%
CLD3 .36 .31 40%



Meets IECC 2018 requirements in all climate zones.

fall safetySAFETY CONSIDERATIONS:

Skylights pose an inherent risk of injury or death from fall throughs, and the safety of others is of the utmost importance to VELUX. VELUX recommends that the customer, building owner or manager use additional protection with the skylight such as an exterior or interior safety cage, to enhance long-term safety. The building owner or manager is responsible for providing fall protection around the skylight in accordance with OSHA regulations. VELUX also recommends that the building owner or manager restrict roof access only to personnel who have been cautioned as to the location of the skylights, and warned not to sit, step or walk on the skylights.
